KEY FEATURES
• EN/DIN and new SAE rated working pressures
• Flame retardant property of the cover compound, MSHA approved
• Smooth cover FRAS approved (DN 5-12)
• Halogen-Free hose line
APPLICATIONS & FLUIDS
• Hydraulics: low-medium pressure lines, return lines
• Mineral oils, vegetable and rape seed oils, glycol and polyglycol based oils, synthetic ester based oils, oils in aqueous emulsion, water
CONTINUOUS SERVICE TEMPERATURE RANGE
-40 °C, -40 °F
100 °C, 212 °F
TUBE
Oil resistant synthetic rubber
REINFORCEMENT
One high tensile steel braid
COVER
Weather resistant synthetic rubber
APPLICABLE SPECS
EN 853 1SN; SAE 100 R1AT; ISO 1436 1SN/R1AT
TYPE APPROVALS
MSHA, CU-TR
